Safari VSPEC Snorkel for Ford Ranger PJ & PK

$495.00
*Availability may change without notice due to high demand Australia wide during COVID-19. Please call us on 03 99311160 to confirm stock before purchase, or we can pre-order for you if needed.

Available Options


Calculate Shipping

The SS970R Ford Ranger 4x4 Snorkel is designed to deliver a huge volume of the coolest and cleanest air possible into the stock air cleaner assembly of all PJ 12/2006 - 03/2009 3.0L Diesel engines & PK 04/2009 - 07/2011 3.0L Diesel engines.

With the huge air flow demands of each engine in the PJ 12/2006 - 03/2009 3.0L Diesel engines & PK 04/2009 - 07/2011 3.0L Diesel Ford Ranger, Safari took the decision to design a snorkel system that raised the air intake to prevent ingesting harmful elements to the vehicles air cleaner.

Huge air flow is but one aspect of the ultimate in snorkel Ford Ranger design. The Safari snorkel air ram is designed to perform two very important roles. The most obvious is to funnel cool clean air into the snorkel body - but just as importantly, the Safari air ram acts as a highly efficient water separator to remove rain water from the incoming air stream - thus ensuring safe engine operation through even the most torrential tropical storms.

The genuine Safari Ford Ranger 4x4 Snorkel body and air ram is manufactured to the highest standards in durable, UV stable, cross linked polyethylene material. In addition, the substantial material wall thickness delivers huge physical strength to ensure that the Ford Ranger snorkel breezes through the toughest off-road conditions on the planet.

  • Safari Automotive Australian designed, moulded and manufactured
  • Raised air intake to prevent your engine from ingesting harmful elements
  • Increased airflow for your PK 04/2009 - 07/2011 3.0L Diesel engine
  • Water separating air ram design to remove water from the air stream
  • Durable and UV stable snorkel and air ram for added strength
  • Comprehensive Ford Ranger 4WD Snorkel fitting guide with an accurate template for assisting with installation.

ITEM

PART NO.

DESCRIPTION

QTY

1

630-133-200R

BODY - SNORKEL

1

2

000-135-650

3 1/2" AIR RAM ASSEMBLY

1

3

630-024-200

HOSE - AIR ENTRY

1

4

630-023-000

ADAPTOR - AIR CLEANER

2

5

630-032-200

BRACKET - UPPER MOUNTING

1

6

000-958-300

POP RIVET - 4.8mm x 12mm

4

7

000-002-100

BOLT - HEX - 6mm x 1.0 x 14mm (SEMS)

3

8

000-110

STUD - S/S - 8mm x 1.25 x 25mm - O/L

7

9

000-311-300

WASHER - BODY - 8mm x 30mm

7

10

000-205-300

NUT - NYLOC - 8mm x 1.25mm

7

11

000-958-400

POP RIVET - 4.8mm x 21mm

2

12

000-909

CLAMP - HOSE - 80/100mm

2

13

000-914/B

HOSE CLAMP - SIZE 56 (BLACK)

1

14

630-017-200

TEMPLATE

1

(SS970HF)

SKU SS970HF
Brand Safari 4x4
Shipping Weight 5.3000kg
Shipping Width 0.420m
Shipping Height 0.200m
Shipping Length 1.290m
Shipping Cubic 0.108360000m3
