Safari Snorkel for Ford Everest 3.2L Diesel models 08/2015+

Safari VSPEC Snorkel for Ford Everest 3.2L & 2L Diesel models 08/2015+

Calculate Shipping

Postage Quote required POA
Postage Quote available by contacting us on (03) 9931 1160 or email to info@traxindustries.com.au. Or we will manually apply Postage Quote to your order which will require additional payment to finalize delivery. **** IMPORTANT NOTE **** Due to ongoing increase in transport costs, deliveries of large items (on Pallet) are not economical to ship to a residential address. If there is no other option of shipping other than residential address, email us your shipping address to info@traxindustries.com.au to get freight cost BEFORE placing the order TO AVOID ORDER CANCELLATION FEE.

Description
Specifications

Safari Ford Everest 4x4 Snorkel Features

Safari Automotive Australian designed, moulded and manufactured
Raised air intake to prevent your engine from ingesting harmful elements
Increased airflow for your Ford Everest 08/2015 Onwards 3.2L Diesel engine
Water separating air ram design to remove water from the air stream
Durable and UV stable snorkel and air ram for added strength
Comprehensive Ford Everest 4WD Snorkel fitting guide with an accurate template for assisting with installation.

ITEM	PART NO.	DESCRIPTION	QTY
1	680-133-300	BODY - SNORKEL (SS982HF)	1
2	000-135-800	3 ½" AIR RAM ASSEMBLY	1
3	680-032-300	BRACKET - UPPER MOUNTING	1
4	000-002-100	BOLT - HEX - 6mm x 1.0 x 14mm (SEMS)	2
5	000-951	SCREW - S/T - 4.2mm x 13mm - S/S	3
6	000-960	INSERT - PLASTIC	3
7	000-110	STUD - 8mm x 1.25 x 25mm - S/S	6
8	000-311-300	WASHER - BODY - 8mm x 30mm - S/S	6
9	000-205-300	NUT - NYLOC - 8mm x 1.25mm - S/S	6
10	680-024-400	HOSE - AIR ENTRY	1
11	680-025-400	PLATE - HOSE SUPPORT	1
12	000-094-300	BOLT - B/H CAP SCREW 4mm x 0.7mm x 20mm - S/S	6
13	000-096-300	BOLT - B/H CAP SCREW 4mm x 0.7mm x 30mm - S/S	1
14	000-300-350	WASHER - BODY 4mm x 11mm - S/S	7
15	000-223-300	NUT - NYLOC - 4mm x 0.7mm - S/S	7
16	680-217-000	TEMPLATE - AIR CLEANER (UPPER)	1
17	680-217-200	TEMPLATE - AIR CLEANER (LOWER)	1
18	680-959-000	PLUG - AIR INLET BLANK-OFF	1
19	000-910	HOSE - 90/110mm	1
20	000-914/B	CLAMP - HOSE - SIZE 56 (BLACK)	1
21	680-017-400	TEMPLATE - GUARD PANEL (SS984HF)	1

(SS984HF)

SKU	SS984HF
Brand	Safari 4x4
Shipping Weight	5.3000kg
Shipping Width	0.420m
Shipping Height	0.200m
Shipping Length	1.290m
Shipping Cubic	0.108360000m3
